Baying enclosure system VX25 Basic enclosure
Part No.:
8405000
Brand:
Availability:
Forward delivery 4-6 weeks
Part No. | 8405000 |
---|---|
UOM | EA |
Packaging Unit | EA |
Material | Enclosure frame: Sheet steel, 1.5 mm Roof: Sheet steel, 1.5 mm Door: Sheet steel, 2.0 mm Rear panel: Sheet steel, 1.5 mm Gland plates: Sheet steel, 1.5 mm Mounting plate: Sheet steel, 3.0 mm |
Protection category IP ACC IEC 60529 | IP 55 |
Protection category NEMA | NEMA 12 |
Scope of delivery | Enclosure frame Door(s) Door hinged on the right, may be swapped to the left Roof plate Rear panel Gland plates Mounting plate 2 punched rails 18 x 39 mm Lock: 3 mm double-bit |
Weight (KG) | 73.00 |
---|---|
Dimension Width (mm) | 400.00 |
Dimension Height (mm) | 2,000.00 |
Dimension Depth (mm) | 500.00 |
Description
VX Baying enclosure system, WHD: 400x2000x500 mm, sheet steel, with mounting plate, single door at the front
