Eaton Moeller® series EMR6 Overcurrent monitor
Article No.:
184755
Part No.:
EMR6-I15-B-1
Brand:
Overcurrent monitor, Current measuring range: 0.3 - 1.5 A, 1 - 5 A, 3 - 15 A, Supply voltage: 220 - 240 V AC, 50/60 Hz
Availability:
Forward delivery 6-9 weeks
| Part No. | EMR6-I15-B-1 |
|---|---|
| UOM | EA |
| Weight (KG) | 0.18 |
|---|---|
| Dimension Width (mm) | 22.50 |
| Dimension Height (mm) | 85.60 |
| Dimension Depth (mm) | 103.70 |
Description
Current monitoring relays, Product range: EMR Measuring and monitoring relays, Monitoring of single-phase DC and AC networks, On delay: None = 0 or adjustable from 0.1 to 30 s, Extension of the measurement range possible with current transformers, Monitoring of: Overcurrent, Undercurrent, Current measuring range: I?/I= 0.3 - 1.5 A, 1 - 5 A, 3 - 15 A A, Supply voltage: 220 - 240 V AC, 50/60 Hz, Mounting position: As required, Fixing: Snap fixing, top-hat rail IEC/EN 60715, Width: 22.5 mm, Standards: UL 508, CAN/CSA C22.2 No.14, GL, EAC, CCC, RMRS
Resources / Data Sheets
