Wiring Accessories

DILM150-XVB - Connector, for DILM40-65

ZAV-P5 - Shaft extension, for P5, L=480mm

T0-3-15683/I1/SVB-SW - Main switch, T0, 20 A, surface mounting, 3 contact unit(s), 3 pole, 2 N/O, 1 N/C, STOP function, With black rotary handle and locking ring, Lockable in the 0 (Off) position

TSQD1CO - Series connection time switch 24 hrs., series connection time switch, autonomy, 3 TLE

PKE-XRH - Door coupling handle, red yellow, for PKE

Eaton Moeller® series PKE Accessory Door coupling handle

DILM65-XRL - Reversing wiring kit DILM40 to DILM72

P3-100/IVS - On-Off switch, P3, 100 A, service distribution board mounting, 3 pole, with black thumb grip and front plate, Lockable in the 0 (Off) position

B3.1/2-PKZ0 - Three-phase busbar link, Circuit-breaker: 2, 99 mm, For PKZM0-... or PKE12, PKE32 without side mounted auxiliary contacts or voltage releases

Overload relay, electronic, 20-100A

Auxiliary contact, operates as an early-make contact, 2N/O early

Step switches, Contacts: 6, 20 A, front plate: 0-2, 45 °, 2 steps, 45°, maintained, flush mounting

Changeoverswitches, Contacts: 4, 20 A, front plate: 2>0<1, 45 °, momentary, flush mounting

On-Off switch, 2 pole, 20 A, 90 °, flush mounting

Control transformer, 200VA, 1p, primary 400V, secondary 230V

Control transformer, 100VA, 1p, primary 400V, secondary 24V

Control transformer, 60VA, 1p, primary 400V, secondary 230V

Power supply unit, 3-phase, 400-500VAC/24VDC, 10A

Power supply unit, 3-phase, 400-500VAC/24VDC, 5A

On-Off switch, 3 pole, 63 A, flush mounting

Main switch, 3 pole, 32 A, Emergency-Stop function, Lockable in the 0 (Off) position, rear mounting

Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection

Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection

Position switch, 1N/O+1N/C, rounded plunger

RC suppressor circuit, 110-240VAC, for DILM40-95

Auxiliary contact module, 1N/O, side, screw connection

Auxiliary contact module, 1 N/C, side, screw connection

Insulated enclosure, HxWxD=160x100x100mm, +mounting plate

Busbar adapter, 55mm, 63A, 2TS

Busbar adapter, 45mm, 16A, 2TS cage

Busbar adapter, 45mm, 32A, 2TS

RJ45 CAT 6.  Y7-175548

16A SCHUKO SOCKET.  F9317

63NHG00B - Fuse-link, low voltage, 63 A, AC 500 V, NH00, gL/gG, IEC, dual indicator

Changeoverswitches, Contacts: 8, 63 A, front plate: 1-0-2, 90 °, maintained, surface mounting

Main switch, 6 pole + 1 N/O + 1 N/C, 63 A, Emergency-Stop function, 90 °, Lockable in the 0 (Off) position, surface mounting

Changeoverswitches, Contacts: 8, 32 A, front plate: 1-0-2, 90 °, maintained, surface mounting

Main switch, 4 pole, 63 A, Emergency-Stop function, 90 °, flush mounting

Residual-current circuit breaker trip block for FAZ, 63A, 2p, 30mA, type A

Over current switch, 63A, 2p, C-Char, AC
