Compact basic power distribution. Thanks to the PDU basic, any IT rack can easily be equipped with a professional power distribution system. Depending on the PDU design, horizontal mounting in the 482.6 mm (19") level or vertical mounting (including in the zero-U space) is possible.
For vertical mounting, it may be attached in the zero-U space of the Rittal VX IT or TS IT rack with no need for tools Colour coding of phases and fuse circuits (L1=pink, L2=black, L3=white) Tool-free divider kit for VX IT .
| Product description | DK PDU basic, compact basic power distribution, WLD: 44x1095x70 mm, IEC 60 320: 18xC13, 3xC19 + 6x earthing pin, 230 V, 3~, 16 |
| Material | Extruded aluminium section, anodised , Slots: Plastic |
| Supply includes | Connector lock for IEC C14 and C20 connectors , Assembly parts |
| Options | Type 3 overvoltage protection with interchangeable arresters while operational, with status monitoring, suitable for integration into PDU enclosure . Other enclosure colours are available |
| No. of sockets and type | 18 x C13 / 3 x C19 , 6 x earthing-pin sockets |
| Rated operating voltage | 400 V (AC) , 16 A, 11 kW |
| Infeeds | Qty.: 3 , Phases per infeed: 3~ |
| Length of connection cable | 3 m |
| Type of electrical connection | CEE |
| Directives | EMC Directive 2014/30/EU , Low Voltage Directive 2014/35/EU |
| Standards | EN 62368-1 , EN 61000-3, EN 61000-4, EN 61000-6 , EN 62053-21 |
| Temperature range | Operating : 5 °C...50 °C , Ambient humidity : 10...95 % , Storage : -20 °C...70 °C |
| To fit | Enclosure type: VX IT enclosure frame: ≥ 1,200 mm, Enclosure type: VX IT 19" mounting angles: ≥ 1,200 mm |
| Weight | Net : 4.5 kg, Gross : 4.5 kg |
| ETIM 9 , ETIM 8 | EC002762 |
| ECLASS 8.0 | 27142604 |
